FSI-JB-564 / Plumbing Draftsman
Fatherson International FZEJobsCloseBy Editorial Insights
Fatherson International FZE is seeking a Plumbing Draftsman with 3-5 years of relevant experience in high-rise building projects to prepare detailed plumbing shop drawings, sanitary drainage, soil and waste, and water supply drawings, plus plumbing coordination drawings and as-built updates. The role requires strong AutoCAD proficiency and preferably Revit MEP/BIM, and the ability to read architectural, structural and MEP drawings, while maintaining standards, revisions and documentation. You will coordinate with HVAC, electrical, architectural and structural teams, review drawings for clashes, and incorporate consultant or client comments, providing technical drafting support to site and project teams. To apply, tailor your resume to highlight high-rise projects, include examples of shop drawings or BIM work, emphasize coordination and clash detection, and mention readiness to work onsite in Ras Al Khaimah, UAE.
Plumbing Draftsman – Job Description
Job Responsibilities
- Prepare detailed plumbing shop drawings for high-rise building projects.
- Develop sanitary drainage, soil & waste, and water supply drawings .
- Prepare plumbing coordination drawings and coordinate with HVAC, electrical, architectural, and structural disciplines.
- Prepare as-built drawings based on site requirements and approved modifications.
- Develop detailed layouts, sections, riser diagrams, and plumbing schematics.
- Ensure drawings comply with project specifications, authority requirements, and approved design documents .
- Review architectural and MEP drawings to identify clashes and discrepancies.
- Coordinate with site engineers, MEP coordinators, consultants, and subcontractors.
- Incorporate consultant/client comments and revise drawings accordingly.
- Prepare drawings using AutoCAD and, preferably, Revit MEP/BIM .
- Maintain proper drawing standards, revisions, and documentation.
- Provide technical drafting support to the site and project teams.
Required Skills & Qualifications
- Diploma/Degree in Mechanical Engineering, MEP, or related field preferred.
- 3–5+ years of experience as a Plumbing Draftsman.
- Proven experience in high-rise building projects is required.
-
Strong knowledge of:
- Sanitary drainage systems
- Soil and waste systems
- Water supply systems
- Hot & cold water systems
- Plumbing risers and schematics
- Pump rooms and water tanks
- Plumbing coordination drawings
- Proficiency in AutoCAD is mandatory.
- Knowledge of Revit MEP/BIM is an advantage.
- Ability to read and understand architectural, structural, and MEP drawings.
- Good knowledge of MEP coordination and clash detection.
