Plumbing Draftsman

Fatherson International FZE
1 day ago
Full-time
On-site
https://maps.app.goo.gl/Jbibu7jmu8WbngiS7, United Arab Emirates

JobsCloseBy Editorial Insights

Fatherson International FZE is seeking a Plumbing Draftsman for full-time on-site work in the United Arab Emirates. You will prepare AutoCAD shop drawings for domestic water supply, drainage, storm water, irrigation, pump rooms and water tanks, and develop builders' work and coordinated MEP drawings while managing as-built documentation and drawing registers. The role requires 3 to 5 years of experience with high-rise and villa projects, strong AutoCAD skills, knowledge of UAE plumbing codes and DEWA, and the ability to read architectural, structural and MEP drawings with excellent coordination. Tips for applicants: tailor your CV to highlight relevant projects, include a drawings portfolio, and note immediate availability.

Key Responsibilities

  • Prepare detailed plumbing shop drawings using AutoCAD .
  • Develop layouts for:
    • Domestic Water Supply Systems
    • Drainage Systems
    • Storm Water Systems
    • Irrigation Systems
    • Pump Rooms
    • Water Tanks
  • Prepare builders' work drawings and coordinated MEP drawings for site execution.
  • Coordinate plumbing services with Architectural, Structural, HVAC, Electrical, and Fire Fighting disciplines.
  • Review consultant drawings and revise shop drawings based on consultant comments and site requirements.
  • Ensure all drawings comply with project specifications, UAE authority regulations, and international standards.
  • Coordinate with engineers, consultants, subcontractors, and site teams to resolve drawing-related issues.
  • Prepare as-built drawings upon project completion.
  • Maintain drawing registers and ensure timely submission of project documentation.
  • Support the project team in achieving project milestones and deadlines.

Requirements

  • Minimum 3–5 years of experience as a Plumbing Draftsman.
  • Mandatory experience in High-Rise Building and Villa projects.
  • Strong proficiency in AutoCAD .
  • Good knowledge of plumbing systems, including:
    • Domestic Water Supply
    • Drainage
    • Storm Water
    • Irrigation
    • Pump Rooms
    • Water Storage Tanks
  • Ability to prepare shop drawings, coordination drawings, builders' work drawings, and as-built drawings.
  • Familiarity with UAE plumbing codes, DEWA requirements, and local authority regulations.
  • Ability to read and interpret Architectural, Structural, and MEP drawings.
  • Strong coordination and communication skills.
  • Ability to work independently and meet project deadlines.
  • Immediate joiners are preferred.
