Fatherson International FZE is seeking a Plumbing Draftsman to produce detailed plumbing, drainage, water supply and firefighting drawings for residential, commercial and industrial projects in Sharjah. The role involves converting designs into accurate CAD drawings and Revit MEP models, producing shop, coordination and as-built drawings, and ensuring compliance with local codes and company standards. You will interpret specifications, resolve design conflicts with multidisciplinary teams, prepare material take-offs, and maintain drawing records throughout the project lifecycle while supporting installation and commissioning. The ideal candidate has a diploma or certification in drafting or mechanical engineering, 2 to 5 years of relevant experience, strong AutoCAD and Revit MEP skills, and excellent attention to detail and communication. Apply with a focused resume and portfolio showing software proficiency, on site revisions, and teamwork.

Plumbing Draftsman

A Plumbing Draftsman is responsible for preparing detailed technical drawings and layouts for plumbing, drainage, water supply, and firefighting systems in residential, commercial, and industrial projects. The role involves converting engineering designs and specifications into accurate CAD drawings while ensuring compliance with project requirements, local regulations, and industry standards.

Key Responsibilities:

  • Prepare detailed plumbing and drainage drawings using AutoCAD, Revit, or other drafting software.
  • Develop shop drawings, coordination drawings, and as-built drawings for plumbing systems.
  • Interpret engineering designs, specifications, and project requirements.
  • Coordinate with mechanical engineers, architects, structural engineers, and project teams to resolve design conflicts.
  • Prepare material take-offs and assist in quantity estimation.
  • Update drawings based on site conditions, revisions, and client requirements.
  • Ensure drawings comply with local codes, standards, and company procedures.
  • Maintain accurate documentation and drawing records throughout the project lifecycle.
  • Support project teams during installation and commissioning phases.

Qualifications and Skills:

  • Diploma or certification in Mechanical Engineering, Drafting, or a related field.
  • Proficiency in AutoCAD, Revit MEP, and other drafting software.
  • Strong understanding of plumbing, drainage, water supply, and firefighting systems.
  • Knowledge of construction drawings, building codes, and industry standards.
  • Excellent attention to detail and problem-solving skills.
  • Ability to work collaboratively with multidisciplinary teams.
  • Good communication and organizational skills.

Experience:

  • Typically 2–5 years of experience in plumbing drafting for construction or MEP projects.
  • Experience in residential, commercial, or industrial building projects is preferred.
